| SPECIFICATION | |
| Throat Size | 2", 50.80mm |
| Nominal Impedance* | 8Ω |
| Minimum Impedance | 7.1 ohm @ 3.4 kHz |
| Power Rating** | 100 W (AES) |
| Resonance | 0.47kHz |
| Usable Frequency Range | 800Hz-20kHz |
| Recommended Crossover | 800 Hz / 12 dBkHz |
| Sensitivity*** | 108.80 |
| Magnet Material | Ferrite |
| Magnet Weight | 80oz, 2.27kg |
| Voice Coil Diameter | 3" / 76.20mm |
| Voice Coil Former | Polyimide |
| Diaphragm Material | Titanium w/ geodesic ribs for increased stiffness and break-up control. |
| DC Resistance (Re) | 4.80Ω |
| MOUNTING INFORMATION | |
| Overall Diameter | 7.90", 200.70mm |
| Driver Volume Displaced | 0.04 cu.ft., 1.36 liters |
| Depth | 3.10", 78.70mm |
| Weight | 13.20 lbs, 6 kg |
| Mounting Thread | N/A |
| Mounting Holes Diameter | 4X 1/4-20 |
| Mounting Holes B.C.D. | 4 in. 101.6 mm |
