220 W continuous program power capacity
2" horn throat diameter
75 mm (3 in) aluminium voice coil
Titanium diaphragm
500 - 18000 Hz response
107 dB sensitivity
Shorting copper cap for extended HF response
Teknik Özellikler:
- Throat diameter 50 mm (2.0 in)
- Nominal impedance 8 Ω
- Minimum impedance 8.2 Ω
- Nominal power handling * 110 W
- Continuous power handling * 220 W
- Sensitivity (1W/1m) * 107.0 dB
- Frequency range 1 - 18 kHz
- Recommended crossover * 1.0 kHz
- Voice coil diameter 75 mm (3.0 in)
- Winding material Aluminium
- Inductance 0.14 mH
- Diaphragm material Titanium
- Flux density 1.8 T
- Magnet material Ceramic
- Mounting And Shipping Info
- Four M6 holes 90° on 102 mm (4 in) diameter
- Overall diameter 170 mm (6.7 in)
- Depth 64 mm (2.5 in)
- Net weight 4.5 kg (9.9 lb)
- Shipping units 2
- Shipping weight 9.6 kg (21.2 lb)
- Shipping box 210x210x190 mm (8.3x8.3x7.5 in)
