50 W continuous program power capacity
1" horn throat diameter
36 mm (1.4 in) aluminium voice coil
Polyester diaphragm
1500 - 18000 Hz response
106 dB sensitivity
Teknik Özellikler:
- Throat diameter 25 mm (1.0 in)
- Nominal impedance 8 Ω
- Minimum impedance 7.8 Ω
- Nominal power handling * 25 W
- Continuous power handling * 50 W
- Sensitivity (1W/1m) * 106.0 dB
- Frequency range 2 - 18 kHz
- Recommended crossover * 2.2 kHz
- Voice coil diameter 36 mm (1.4 in)
- Winding material Aluminium
- Inductance 0.14 mH
- Diaphragm material Mylar
- Flux density 1.45 T
- Magnet material Ceramic
- Mounting And Shipping Info
- Two M5 holes 180° on 76 mm (3 in) diameter
- Overall diameter 90 mm (3.5 in)
- Depth 49 mm (2.0 in)
- Net weight 1.0 kg (2.2 lb)
- Shipping units 8
- Shipping weight 8.9 kg (20.0 lb)
- Shipping box 220x220x150 mm (8.7x8.7x5.9 in)
