100 W continuous program power capacity
1' horn throat diameter
44 mm (1.7 in) aluminium voice coil
Titanium diaphragm
1200 - 18000 Hz response
106 dB sensitivity
Compact Neodymium magnet assembly
Shorting copper cap for extended HF response
Teknik Özellikler:
- Throat diameter 25 mm (1.0 in)
- Nominal impedance 8 Ω
- Minimum impedance 7.7 Ω
- Nominal power handling * 50 W
- Continuous power handling * 100 W
- Sensitivity (1W/1m) * 106.0 dB
- Frequency range 1 - 18 kHz
- Recommended crossover * 1.5 kHz
- Voice coil diameter 44 mm (1.7 in)
- Winding material Aluminium
- Inductance 0.11 mH
- Diaphragm material Titanium
- Flux density 1.8 T
- Magnet material Neodymium Ring
- Mounting And Shipping Info
- Two M6 holes 180° on 76 mm (3 in) diameter
- Overall diameter 85 mm (3.3 in)
- Depth 44 mm (1.7 in)
- Net weight 0.8 kg (1.8 lb)
- Shipping units 8
- Shipping weight 6.7 kg (14.7 lb)
- Shipping box 220x220x150 mm (8.7x8.7x5.9 in)
