| GENERAL SPECIFICATIONS | ||
| Nominal diameter | mm (in) | 165 (6.5) |
| Nominal Impedance | Ohm | 8 |
| Minimum impedance | Ohm | 6,8 |
| Program power | W | 300 |
| AES Power rating | W | 150 |
| Sensitivity | dB | 95.5 |
| Frequency range | Hz | 170 ÷ 6000 |
| Voice coil diameter | mm (in) | 45 (1.8) |
| Chassis material | Aluminium | |
| Magnet material | Neodymium | |
| Magnet dimensions OD x ID x h | mm (in) | 85 x 55 x 7 (3.35 x 2.2 x 0.28) |
| Coil material | CCAW | |
| Former material | Glass Fiber | |
| Cone material | Water Resistant Treated Paper + Water Proof Front Side Treatment | |
| Surround material | Polycotton | |
| Xmax | mm (in) | 3 (0.12) |
| Xmech | mm (in) | 5,5 (0.22) |
| Gap height | mm (in) | 6 (0.24) |
| Voice coil winding height | mm (in) | 9 (0.35) |
| Driver displacement volume | l (ft³) | 0,4 (0.01) |
| Recommended Enclosure | l (ft³) | 7 (0.25) |
| Recommended Tuning | Hz | Sealed |
| SMALL SIGNAL PARAMETERS | ||
| DC resistance (Re) | Ohm | 5,56 |
| Resonance frequency (Fs) | Hz | 172 |
| Moving mass (Mms) | g (oz) | 13,26 (0.47) |
| Compliance (Cms) | mm/N | 0,065 |
| Force factor (Bxl) | N/A | 11,03 |
| Mechanical Q-factor (Qms) | 4,69 | |
| Electrical Q-factor (Qes) | 0,65 | |
| Total Q-factor (Qts) | 0,57 | |
| Equivalent air volume (Vas) | l (ft3) | 1,99 (56.4) |
| Voice coil inductance (Le) | mH | 0,087 |
| Diaphragm area (Sd) | cm2 (in.2) | 147,4 (22.8) |
| Reference efficiency (Eta 0) | 1,49 % | |
| Efficiency bandwidth product (EBP) | Hz | 265 |
| SHIPPING INFORMATION | ||
| Net weight | kg (lb) | 1,2 (2.5) |
| Multipack size W x D x H | mm x mm x mm (in x in x in) | 410 x 370 x 208 (16.1 x 14.6 x 8.2) |
| Multipack weight | kg (lb) | 12,8 (28.2) |
