160 W continuous program power capacity
1.5" horn throat diameter
75 mm (3 in) aluminium voice coil
Titanium diaphragm
500 - 18000 Hz response
107.5 dB sensitivity
Shorting copper cap for extended HF response
Teknik Özellikler:
- Throat diameter 38 mm (1.5 in)
- Nominal impedance 8 Ω
- Minimum impedance 8.4 Ω
- Nominal power handling * 110 W
- Continuous power handling * 220 W
- Sensitivity (1W/1m) * 107.5 dB
- Frequency range 1 - 18 kHz
- Recommended crossover * 0.8 kHz
- Voice coil diameter 75 mm (3.0 in)
- Winding material Aluminium
- Inductance 0.14 mH
- Diaphragm material Titanium
- Flux density 1.9 T
- Magnet material Ceramic
- Mounting And Shipping Info
- Four M6 holes 90° on 102 mm (4 in) diameter
- Overall diameter 180 mm (7.1 in)
- Depth 70 mm (2.8 in)
- Net weight 6.0 kg (13.2 lb)
- Shipping units 1
- Shipping weight 6.2 kg (13.6 lb)
- Shipping box 190x190x100 mm (7.5x7.5x3.9 in)
