| Frequency Response (-10) | 65Hz - 20kHz |
|---|---|
| Frequency Response (-3) | 100Hz - 18KHz |
| Power | 200W AES, 800W Peak |
| Sensitivity (1W/1M) | 94dB |
| Max SPL (1M) (Peak) | 123dB |
| Nominal System Impedance | 16 Ohms |
| Input Connector | NL4 ±1 Twist Lock Connector |
| Link Connector | NL4 ±1 Twist Lock Connector |
| HF Driver | 1 x 1.33 Inch Celestion Compression Driver, mounted to Celestion Designed wave guide and horn |
| LF Driver | 2 x 5 Inch HH designed driver |
| Crossover Frequency | 2000HZ |
| Nominal Dispersion | 120° x 60° (120° x 30° single point) |
| Splay Angle Settings | Dual Angle, 0° and 8° |
|---|---|
| Recommended HPF Frequency | 100Hz |
| Cabinet | 15mm Plywood |
| Finish | Painted Black (White finish optional, subject to MOQ) |
| Mounting Bracket | TNA-BRK1 for suspended mounting |
| Mounting Points | M8 fixings for optional TNA-BRK1 flying bracket assembly (available separately) |
| Grille | 1.5mm Thickness Steel, Hexagonal mesh, acoustic foam lined |
| Unit Dimensions (Hwd) | 158 x 460 x 265mm / 6.2" x 18.1" x 10.4" |
| Unit Weight | 8.4 Kg, 18.5 lbs (each) |
| Carton Dimensions (Hwd) | 410 x 330 x 530mm, 16.1" x 13" x 20.9" |
| Packed Weight | 18.4 Kg, 40.6 lbs (2pcs per carton) |
