Shure - QLXD24E/B58 El Tipi Kapsül Telsiz Mikrofon Seti

Shure QLXD24E/B58 El Tipi Kapsül Telsiz Mikrofon Seti

The Shure ULX Series wireless microphone systems provide professional wireless microphone solutions for broadcast, performances, conferences, houses of worship, schools, and businesses. This wireless handheld system includes the ULXP4 receiver, and ULX2 handheld transmitter with a Shure Beta 58 supercardioid head.

ULXP4 Diversity Receiver

ULX2 Handheld Transmitter

Shure Beta 58 Capsule

                 Frekans

J1 - 554 / 590 Mhz

M1 - 662 - 698 Mhz

G3 - 470 / 506 Mhz

System

Type of System Rack/Table Top Mountable UHF Diversity Wireless Handheld System

RF Carrier Frequency Range 554.000 to 865.000MHz

Approx. Working Range 300 Feet (100m) NOTE: Actual working range depends on RF signal absorption, reflection, and interference

Overall Frequency Response 25Hz - 15kHz, (±2dB)

Signal-to-Noise Ratio Greater Than 90dB

# Of Channels Over 1400 User Selectable Frequencies (Frequency G3 / 470 - 505 MHz)

# Of Simultaneous Systems Up to 20

Receiver

Type of Receiver ULXP4 Professional Rack/Table-Top Mount Receiver

Type of Outputs Balanced XLR - 22 Ohms, 1 = Ground, 2 = Hot, 3 = Cold

Unbalanced 1/4" Phone Jack - 3k Ohms, Tip = Hot, Ring/Sleeve = Gnd

(Both Outputs Feature: Voltage, Current and Phantom Power Protection)

Headphone Monitoring No

Power Requirements 14 - 18VDC (negative ground), 550 mA

External Power Supply - PS40, Included, Now with Locking DC Connector!

Battery Type/Approx. Life Not Applicable, Unit Does Not Operate on Batteries

Display Yes, Power On Indicator, Diversity Signal Indicators and Audio Peak Indicator, Channel, Group, Transmitter Low Battery Warning.

Mounting Options Rack / Table Top Mount 1/2 Rack Space

Antenna Type Internal

Dimensions 1.72 x 8.56 x 6.88" (43 x 214 x 172mm) HxWxD

Weight 10.4 oz. (296 g)

Transmitter

Type of Transmitter ULX2/BETA58 Handheld UHF Transmitter

Type of Input Connector Microphone Element is Attached (Screwed On) to Transmitter

Type of Microphone BETA58 Dynamic Microphone Head

Polar Pattern Supercardioid

Interchangeable Mic Heads No

Battery Type/Approx. Life Non-Rechargeable Type

9V Lithium Battery / 21 Hours (Recommended)

9V Alkaline Battery / 8 - 9 Hours (Recommended)

9V Carbon-Zinc Battery / 5 Hours (NOT Recommended)

Rechargeable Type

9V Ni-Cad Battery / 2 Hours (NOT Recommended)

9V Ni-MH Battery / 2.5 Hours (NOT Recommended)

Mute Switch Yes

Level Control Yes, 25 dB Gain Adjustment Range

Antenna Type Remotable 1/2 Wave, Rear Mounted

Display Power On/Off Indicator, 3-Segment Low Battery Indicator, Channel and Group, Peak Icon (Input Overload Warning)

Dimensions (WxDxH) 9.49 x 2.01" (241 x 51mm) LxDiameter

Weight 2 lbs., 7 oz. (1105 g)
