PLAY 12 A

LD Systems PLAY 12 A

Product number: LDPLAY12A

Product type: PA loudspeaker

Type: active

Low/mid driver dimensions: 12"

Low/mid driver dimensions (mm): 304mm

Low/mid driver magnet: Ferrite

Low/mid driver brand: Custom-made

Low/mid driver voice coil: 119"

Tweeter dimensions: 1.35"

Tweeter dimensions (mm): 34mm

Tweeter magnet: Ferrite

Tweeter brand: Custom-made

Amplifier: Class A/B (Bi-amp)

Dispersion (H x V): 90 x 45°

RMS: 250W

Peak power: 1000W

Frequency response: 60 - 18,000Hz

Max. SPL: 119dB

Integrated media player: yes

Protection circuits: DC, overload

Controls: volume, Power, Previous Track, mode, Play / Pause, Treble, Next Track, Mic Gain, Line Gain, Bass, 5-band Master EQ

Indicators: Power, multifunction LC display

Line inputs: 2

Line input connectors: XLR, RCA

Mic inputs: 2, XLR, 6.3 mm Jack

Line outputs: 2

Line output connectors: XLR, 6.3 mm Jack

Operating voltage: transformer, 115 V AC, 60 Hz, 230 V AC, 50 Hz

Cabinet material: polypropylene

Cabinet construction: vented

Width: 425mm

Height: 640mm

Depth: 365mm

Weight: 15.7kg

Features: Ergonomic handle, Infrared Remote Control for Media Player, Speaker Pole Mount (36 mm)
