Teknik Özellikler
131 dB'ye kadar Ses Basıncı Seviyesi
2100W D Sınıfı Çift Amplifikasyon
45-20000 Hz doğrusal frekans yanıtı
1.75" Sıkıştırma Sürücüsü
15" Woofer
FiRPHASE sıfır derece faz teknolojisi
Bas Hareket Kontrolü woofer gezi yönetimi
ACOUSTICAL SPECIFICATIONS
Frequency Response:
45 Hz ÷ 20000 Hz
Max SPL @ 1m:
131 dB
Horizontal coverage angle:
100°
Vertical coverage angle:
60°
TRANSDUCERS
Compression Driver:
1 x 1.0'', 1.75'' v.c
Woofer:
15'', 2.5'' v.c
INPUT/OUTPUT SECTION
Input signal:
bal/unbal
Input connectors:
XLR, Jack
Output connectors:
XLR
Input sensitivity:
-2 dBu/+4 dBu
PROCESSOR SECTION
Crossover Frequencies:
1600 Hz
Protections:
Thermal, RMS
Limiter:
Soft Limiter
Controls:
Linear, Boost, Stage, Volume
POWER SECTION
Total Power:
2100 W Peak
High frequencies:
700 W Peak
Low frequencies:
1400 W Peak
Cooling:
Convection
Connections:
VDE
STANDARD COMPLIANCE
Safety agency:
CE compliant
PHYSICAL SPECIFICATIONS
Cabinet/Case Material:
Plywood
Hardware:
2 x M10 Top, 1 x M10 each side, 1 x M10 bottom, 1 x M10 rear
Handles:
1 x Each Side
Pole mount/Cap:
Yes
Grille:
Steel
Color:
Black
SIZE
Height:
705 mm / 27.76 inches
Width:
420 mm / 16.54 inches
Depth:
451 mm / 17.76 inches
Weight:
24.1 kg / 53.13 lbs
SHIPPING INFORMATIONS
Package Height:
751 mm / 29.57 inches
Package Width:
506 mm / 19.92 inches
Package Depth:
474 mm / 18.66 inches
Package Weight:
26.6 kg / 58.64 lbs
