LD Systems - MON 121 AG2

LD Systems MON 121 AG2

Product number: LDMON121AG2

Product type: stage monitors

Type: active

Low/mid driver dimensions: 12"

Low/mid driver dimensions (mm): 304mm

Woofer type: coaxial loudspeaker

Woofer magnet: Ferrite

Woofer brand: Custom-made

Woofer voice coil: 2"

Woofer voice coil (mm): 50.8mm

HF driver dimensions: 1"

HF driver dimensions (mm): 25.4mm

HF driver magnet: Ferrite

HF driver brand: Custom-made

HF driver voice coil: 1"

HF driver voice coil (mm): 25.4mm

Amplifier: Class A/B

Dispersion (H x V): 75 x 75°

RMS: 250W

Peak power: 1000W

Frequency response: 80 - 20000Hz

Crossover frequency: 2200Hz

SPL (1W/1m): 100dB

Max. SPL (continuous): 116dB

Max. SPL (peak): 124dB

Protection circuits: short circuit, limiter

Controls: volume, On / Off

Indicators: Power, signal, limit

Line Inputs: 1

Line input connectors: XLR, 6.3 mm Jack

Line Outputs: 1

Line output connectors: XLR

Operating voltage: transformer, 230 V AC / 50-60 Hz

Cabinet material: 15 mm Plywood

Cabinet construction: vented

Monitor angle: 35°

Width: 440mm

Depth: 360mm

Height: 514mm

Weight: 17.8kg

Features: ergonomically shaped insert handles
