CONTROL: RS-422
CONNECTORS: 100m Less than
AUDIO INPUT
DIGITAL INPUT(RJ-45 INPUT
OUTPUT LEVEL: 0dBV
INPUT SENSITIVITY(at 0dBV output): 0dBV
S/N (20kHz LPF,A-weight filter): 85dB Better than
T.H.D (at 0dBV output,20kHz LPF): 0.1% Less than
Local Input (XLR input)
INPUT SENSITIVITY(at 0dBV output): -60dBV
S/N (20kHz LPF,A-weight filter): 60dB Better than
T.H.D (at 0dBV output,20kHz LPF): 0.1% Less than
FREQUENCY RESPONSE: 100Hz ~ 20kHz (±3dB)
Local Input (PHONE input)
INPUT SENSITIVITY(at 0dBV output): 0dBV
S/N (20kHz LPF,A-weight filter): 75dB Better than
T.H.D (at 0dBV output,20kHz LPF): 0.1% Less than
FREQUENCY RESPONSE: 100Hz ~ 20kHz (±3dB)
Operation Temperature: -10℃ ~ 40℃
Power Source: AC: 100-240V, 50/60Hz , DC 24V
Power Consumption: 15W
Weight (SET): 6.5kg / 14.33Ib
Dimensions (SET): 440(W)x88(H)x388(D)mm / 17.3(W)x3.46(H)x15.27(D)in
