AUX INPUT(AUX IN @1kHz, 4Ω Load Output)
Rated Output Power: 240W
Input Sensitivity:-10dBV/10kΩ
S/N, AES-17 WTD: ≤ -80dB
Tone Control(BASS:100Hz, TREBLE:10kHz): ±10dB
Frequency Response (1W Power Output, ±3dB): 90Hz-18kHz
T.H.D.: <1%
MIC 1 ~ 6 Input (MIC IN @1kHz, PRE OUT)
Input Sensitivity: -60dBV ~ -16dBV/10kΩ
S/N, A-WTD: ≤ -60dB
Frequency Response (±3dB): 120Hz-10kHz
Phantom Power: +24V DC
Remote IN (Remote IN @1kHz, PRE OUT)
Input Sensitivity: -60dBV/10kΩ
S/N, A-WTD: ≤ -50dB
Frequency Response (±3dB): 120Hz-10kHz
TEL IN (TEL IN @1kHz, PRE OUT)
Input Sensitivity: -2.2dBV/10kΩ
S/N, A-WTD: ≤ -65dB
Frequency Response (±3dB): 330Hz-3kHz
CD (Test CD 0dB, 1kHz @ PRE OUT)
S/N, A-WTD: < -85dB
Frequency Response (±3dB): 80Hz-18kHz
TUNER (FM, 22.5kHz, MOD @ PRE OUT)
S/N, A-WTD: < -60dB
Frequency Response (±3dB): 100Hz-14kHz
PRE OUT (MIC1~6, AUX IN TEL IN, Remote IN)
Output Level: 0dBV/600Ω
T.H.D: < 0.5%
POST OUT /Output Level: 0dBV/600Ω
Operating Temperature: -10°C ~ +40°C
Power Source: 120VAC or 220-240VAC; 50/60Hz, 24VDC**
(Different voltage setting on SMPS depends on country)
Power Consumption(1/8 power): 90W
Weight: 11kg/24.3lb
Dimensions: 420(W) x 132(H) x 380(D)mm/16.5(W) x 5.2(H) x 15(D)in
