Amplifier Section (Amp In@1kHz,4Ω Load Output)
Rated Output Power (THD 1%): 240W(RMS)
Speaker Zone 1~5 Output: 50W MAX
Input Sensitivity/Impedance: 1V/20kΩ
S/N: Better than 85dB
Frequency Response (at 1kHz Half Power Output, ±3dB): 80Hz~18kHz
Mic Input Section (Mic 1~4 In@1kHz,Preamp Out)
Input Sensitivity/Impedance: –60dBV/600Ω
S/N: Better than 55dB
Frequency Response (±3dB): 120Hz~10kHz
Tone Control (Bass:100Hz,Treble:10kHz): ±12dB
Phantom Power: +24VDC
Line Input Section (Line 1~2 In@1kHz,Preamp Out)
Input Sensitivity/Impedance: –30dBV/10kΩ
S/N: Better than 65dB
Frequency Response (±3dB): 80Hz~15kHz
Tone Control: (Bass:100Hz,Treble:10kHz)
Remote Amp Section (Remote In@1kHz,Preamp Out)
Mic Input Sensitivity/Impedance: –60dBV/600Ω
S/N: Better than 55dB
Frequency Response (±3dB): 120Hz~10kHz
Tel In Section (Tel In@1kHz,Preamp Out)
Input Sensitivity/Impedance: 0.3V/600Ω(USA/Canada) 0.775V/600Ω(EC & Associated)
S/N: Better than 65dB
Frequency Response (±3dB): 330Hz~3kHz
Pre Amp Out(Mic 1~4, Line 1~2, Tel In, Remote In): 0dBV/600Ω
T.H.D: Less than 0.5%
Record Out: –10dBV/3kΩ
Operating Temperature: –10°C~40°C
Power Source: 100–120VAC or 220–240VAC; 50/60Hz, 24VDC
Power Consumption (1/8 POWER): 320W
Weight: 19kg/42lb
Dimensions: 19(W) x 5.2(H) x 15.7(D)in
