Yamaha - DHR10 700W Aktif Hoparlör

Teknik Özellikleri

• Tip : 2-way, Bi-amped Powered Speaker, Bass-reflex

• Frekans Aralığı (-10dB) : 52 Hz - 20 kHz

• Crossover : 1.9 kHz: FIR-X tuning™ (linear phase FIR filter)

• Maximum Output Level : 128 dB SPL

• LF : Diameter: 10" cone, Voice Coil: 2", Magnet: Ferrite

• HF : Diaphragm: 1.4", Type: 1" throat compression driver, Magnet: Ferrite

• Amplifier class : Class-D

• Power Rating : 325 W (LF: 260 W, HF: 65 W) - 700 W (LF: 500 W, HF: 200 W) *1

• I/O connectors : INPUT1: Combo x1, INPUT2: Combo x 1 + RCA pin x 2 (Unbalanced), OUTPUT: XLR3-32 x 1 (CH1 Parallel Through or CH1+CH2 Mix)

• Dimensions (W x H x D) : 305×494×300 mm; (12.0"x19.5"x11.8")

• Weight : 15 kg; 33.1 lbs
