The two-way enclosure loaded with a 12“ speaker is so frequently used for
sound reinforcement applications that it has become a de facto standard.
Thanks to its rotatable horn, integrated rigging points, and slanted panel for monitoring, the F12 will serve you well in almost every conceivable application.
Teknik Özellikler:
- Rotatable Horn: YES
- Controller: DSP 24bit/48kHz
- Angles Up: Monitor use 45 °
- Speaker Type: 2-Way Active Speaker
ACOUSTICAL DATA
- Frequency Response [-10dB]: 65 - 20.000 Hz
- Frequency Response [+/- 3dB]: 75 - 19.000 Hz
- Max SPL: 127 dB
- HF: 1 "
- Type HF: Compression driver
- Directivity: 90 x 40°
- Horn: CD Horn
- Rotatable Horn: YES
- LF: 12"
AMPLIFIER
- Amp Technology: Digipro®
- Amp Class: Class D
- Power PRG: 800 W
- Peak Power: 1600 W
PROCESSOR
- Controller: DSP 24bit/48kHz
- System Presets: Flat, Processed
- Limiter: Dual Active Peak, RMS, Thermal
- Crossover Frequency LF-HF: 1300 Hz
- Slope MF-HF: 24 dB/Octave
INPUT
MECHANICS
- Housing: Multiplex
- Angles Up: Monitor use 45 °
- Width: 360 mm (14.4 in)
- Height: 610 mm (24.4 in)
- Depth: 360 mm (14.4 in)
- Weight: 16.5 kg (36.38 lbs)
