SUB 05 D Aktif Subwoofer
The 800W SUB 05 D is an excellent choice for extending 10“ and 12” loudspeakers’ range.
It packs the kind powerful low-end punch necessary for contemporary sounds and pumps out plenty of SPL for live applications.
The unit connects easily and quickly courtesy of a built-in digital stereo crossover (DSP) with adjustable frequency and a phase inversion switch.
Housed in the newly developed H.E.T enclosure featuring integrated control features, this rugged cabinet tough enough to stand up to the rigors of transport.
Teknik Özellikler:
TECHNICAL DATA
- Speaker Type: Active Bandpass Subwoofer
ACOUSTICAL DATA
- Frequency Response [-10dB]: 30 - 150 Hz
- Max SPL: 129 dB
- Directivity: omnidirectional
- LF: 15 "
AMPLIFIER
- Amp Technology: Digipack™
- Amp Class: Class D
- Peak Power: 800 W
PROCESSOR
- Controller: DSP 24 bit/ 48 kHz
- Phase: 0, 180 °
- Limiter: Dual Active Limiter
- Crossover Frequency : 100 Hz, 24dB/Octave
- System Presets: Flat, Boost
INPUT
- Signal Input: 2x XLR
- Signal Output: 2x XLR X-Over Out/ Link Out
MECHANICS
- Housing: Multiplex with H.E.T coating, reinforced
- Width: 490 mm (19.6 in)
- Height: 520 mm (20.5 in)
- Depth: 615 mm (24 in)
- Weight: 29,5 kg (65.04 lbs)
