DB Technologies - DVX D10 HP Aktif Kabin Hoparlör

The DVX D10 HP is an active 10“/1“ two-way speaker cabinet perfect for use in music and speech reinforcement applications demanding true frequency response, balanced dynamic response, and assertive sound pressure levels.

Equipped with a high-quality 10” woofer and a 1“ compression driver with rotatable CD horn, the DVX D10 HP is fullrange enabled and can be deployed for many applications without an added subwoofer.

TECHNICAL DATA

Speaker Type: 2-Way Active Speaker

ACOUSTICAL DATA

Frequency Response [-10dB]: 70 - 20.000 Hz

Frequency Response [+/- 3dB]: 85 - 19.000 Hz

Max SPL: 127 dB

HF: 1 "

Voice Coil HF: Titanium 1.7 "

Directivity: 90x70 °

Horn: CD Horn Aluminium

Rotatable Horn: YES

LF: 10 "

Voice Coil LF:

AMPLIFIER

Amp Technology: Digipro® G2

Amp Class: Class D

Power RMS: 600 W

Peak Power: 1200 W

Cooling: Convection

PROCESSOR

Controller: DSP 24 Bit/48 kHz

System Presets: Flat, Monitor

Limiter: RMS, Peak. Thermal, Multiband

Crossover Frequency MF-HF: 1600 Hz

Slope MF-HF: 24 dB/Octave

INPUT

MECHANICS

Housing: Multiplex birch plywood

Housing Design: Multifunctional

Angles Up: Monitor use 45 °

Rigging Points: 6x M8 2x 10mm Quick Release for DTF-bracket

Flytracks: 3x on top 3x on bottom

Width: 290 mm (11.6 in)

Height: 510 mm (20.4 in)

Depth: 310 mm (12.4 in)

Weight: 15.8 kg (34.83 lbs)
