DVA S1518N Subwoofer, 18“, Bandpass

The DVA S1518N is a bandpass subwoofer based on the DVA S10, but with 50 percent higher power amp output, an integrated DSP, and an RDnet link.

A remarkably versatile subwoofer, it delivers tight and punchy bass response that supports and transitions smoothly to satellites’ lower midrange frequencies.

The DVA S1518N is equipped with a next-generation, 18“ woofer driven by a built-in 1500W digipro® G2 digital power amp.

Subwoofer arrays are easily flown using the optional SRK10 rigging hardware retrofit.

The S1518N will also serve you well in compact stacks paired with DVA T12, T8 and T4 units or DVX Series enclosures.

TECHNICAL DATA

Speaker Type: Active Bandpass Subwoofer

ACOUSTICAL DATA

Frequency Response [+/- 3dB]: 39 - 120 Hz

Max SPL: 138 dB

Directivity: Omnidirectional, Cardiod Option with DSP setup

LF: 18 "

Voice Coil LF: 4 "

AMPLIFIER

Amp Technology: Digipro® G2

Amp Class: Class D

Power Supply: 1.5 kW SMPS

LF Amp: 1500 W RMS

Cooling: Convection

PROCESSOR

Controller: DSP 56 bit

AD/DA Converter: 24bit/ 96 kHz

System Presets: X-Over,Delay

Phase: 0, 180 °

Limiter: RMS, Peak, Thermal

Delay Option: 0-4.5 ms internal

Crossover Frequency LF-MF: 75-120Hz | steps of 5Hz

LF-Xover out slope: 24 dB/Octave

INPUT

MECHANICS

Housing: Multiplex birch plywood

Housing Design: Rectangular

Handles: 3x Per Side

Accessory: Dolly, Wheels 100mm, Dust Cover, Rain Cover

Pole Mount: M20

Rigging Points: integrated for SRK10 fly kit 2xPick Points on top to fix DRK10/20 rigging frames

Width: 515 mm (20.6 in)

Height: 640 mm (25.6 in)

Depth: 720 mm (28.8 in)

Weight: 46 kg (101.41 lbs)
