CPX™ 4

Channels (Input) 2
Channels (Output) 2
Power per Channel @ 2 Ω 800 W
Power per Channel @ 4 Ω 1,600 W
Power per Channel @ 8 Ω 1,005 W
Power per Channel @ 4 Ω Bridged 1,600 W
Power per Channel @ 8 Ω Bridged 3,200 W
Topology Class H
Minimum Load Impedance 2 Ω
Frequency Response 12 Hz – 35 kHz; +0, -2 dB @ 1W
Input Connectors 2 x XLR-1/4″ Combo
Output Connectors 2 x 4-pin Twist-Lock
Color Black
Rack Mount (19″) Yes (2U)
Net Weight 43.0 lbs (19.50 kg)
Product Height 3.50″ (89 mm)
Product Width 19.00″ (483 mm)
Product Depth 16.25″ (413 mm)
AC Power Input Dual Voltage – 115VAC or 220-240VAC, 50/60 Hz
