Frequency Range (-10 dB) | 33Hz – 19kHz | |
Frequency Response (±3 dB) | 42Hz – 14kHz | |
Power Ratings | 250 W (1000 W peak), 2 hrs. 200 W (800 W peak), 100 hrs. | |
Maximum SPL @ 1m | 116 dB continuous (123 dB peak) | |
Nominal Sensitivity | 92 dB | |
Coverage Angle | 110° x 110° | |
Directivity Factor (Q) | 5.7, averaged 500 Hz to 10 kHz | |
Directivity Index (DI) | 7.3 dB, averaged 500 Hz to 10 kHz | |
Nominal Impedance | 8 ohms | |
Crossover Type | 2nd order low-pass, 2nd order high-pass, plus conjugate shaping circuitry. | |
Transformer Taps | 70V: 150W, 75W, 38W, 19W 100V: 150W, 75W, 38W Insertion Loss: <0.65 dB at any tap setting Thru Setting: 8Ω nominal | |
Recommended High-Pass | Protective 40 Hz high-pass (24 dB/oct) for any transformer tap and for 8Ω operation | |
Low Frequency | 250 mm (10 in) woven-fiberglass cone with pure butyl rubber surround, 52 mm (2 in) voice coil on high-temperature fiberglass voice coil former, optimized cone geometry, linear suspension spider, FEA-optimized motor construction, aluminum ring on pole piece. | |
High Frequency | JBL 2414H-C compression driver with 25 mm (1 in) diaphragm and voice coil diameter, high temperature polymer diaphragm, JBL-patented design, fluid-cooled. | |
Enclosure Material | High impact Polystyrene (HIPS) with 10% glass fill plus patent-pending internal 5 mm foamed polyurethane secondary mold for additional cabinet density. | |
Grille | Zinc-plated and thermoset-composite coated steel, WeatherMax™ multi-layer foam with tight-weave mesh vapor barrier. | |
Installation | InvisiBall wall-mounting system included. Ten 6 mm attachment points on cabinet for suspending or for optional U-bracket. One 6 mm secondary safety attachment point (for forged shoulder steel eyebolt, not included) on back panel. | |
Environmental | IP-55 per IEC529. Exceeds MilSpec 810 for humidity, salt-spray, temperature & UV. Passes MilStd-202F for salt spray. Optional MTC-30MK marine-kit grille increases longevity in highly corrosive environments. | |
Termination | Screw-down terminal strip, zinc-plated copper based, nickel-plated metal screws and washers. Accepts up to 9 mm outside 4 mm inside open lugs (#6, #8, or #10 lug), plus bare wire (up to 12 AWG / 2.5 mm2). | |
Agency Rating | Transformer is listed per UL1876 | |
Colors | Black (RAL9004) or white (-WH, RAL9003) | |
Dimensions | 593 x 372 x 345 mm (23.3 x 14.6 x 13.5 in) | |
Weight (ea) | 18.8 kg (41.5lb) | |
Shipping Weight (ea) | 22.0 kg (48.5 lb) | |
Included Accessories | 1 pc MTC-PC2 input panel cover, InvisiBall wall-mounting system, 6 mm x 305 mm InvisiBall hex wrench. | |
Optional Accessories | MTC-30MK Marine-Kit Grille in black or white (-WH), consisting of grille and protective covers for baffle screws. MTC-30CM (&-WH) Ceiling-Mount Adapter for installing speaker down from the ceiling. MTC-30UB (&-WH) U-Bracket |
