500 W continuous program power capacity
64 mm (2.5 in) aluminium voice coil
50 - 3000 Hz response
97 dB sensitivity
Neodymium magnet allows a very light yet powerful motor assembly
Ventilated voice coil gap for reduced power compression
Teknik Özellikler:
Nominal diameter 250 mm (10.0 in)
Nominal impedance 8 Ω
Minimum impedance 7.0 Ω
Nominal power handling * 250 W
Continuous power handling * 500 W
Sensitivity (1W/1m) * 97.0 dB
Frequency range 50 - 3000 Hz
Voice coil diameter 64 mm (2.5 in)
Winding material Aluminium
Former material Glass Fibre
Winding depth 14 mm (0.55 in)
Magnetic gap depth 8 mm (0.31 in)
Flux density 1.25 T
Design
Surround shape Double Roll
Cone shape Exponential
Magnet material Neodymium Inside Slug
Spider Single
Pole design Straight Pole
Woofer cone treatment TWP Waterproof Both Sides
Recommended enclosure 26.0 dm3 (0.92 ft3)
Recommended tuning 62 Hz
Parameters *
Fs 56 Hz
Re 5.7 Ω
Qes 0.29
Qms 3.4
Qts 0.26
Vas 31.0 dm3 (1.1 ft3)
Sd 320.0 cm2 (50.0 in2)
η₀ 1.8 %
Xmax 6.0 mm
Xvar 7.0 mm
Mms 37 g
Bl 16.2 Txm
Le 0.9 mH
EBP 193 Hz
Mounting And Shipping Info
Overall diameter 261 mm (10.3 in)
Bolt circle diameter 245 mm (9.6 in)
Baffle cutout diameter 230.0 mm (8.8 in)
Depth 113 mm (4.4 in)
Flange and gasket thickness 13 mm (0.5 in)
Air volume occupied by driver 1.5 dm3 (0.05 ft3)
Net weight 2.9 kg (6.4 lb)
Shipping weight 3.5 kg (7.7 lb)
Shipping box 330x330x160 mm (13x13x6.3 in)
