| SPECIFICATION | |
| Nominal Basket Diameter | 6", 165 mm |
| Nominal Impedance* | 8 Ω |
| Power Rating** | |
| Watts | 100 W |
| Music Program | 200 W |
| Resonance | 103 Hz |
| Usable Frequency Range | 95 Hz - 6 kHz |
| Sensitivity*** | 93.6 dB |
| Magnet Weight | 20 oz. |
| Gap Height | 0.25", 6.4 mm |
| Voice Coil Diameter | 1.5", 38 mm |
| THIELE & SMALL PARAMETERS | |
| Resonant Frequency (fs) | 103 Hz |
| DC Resistance (Re) | 7.2 Ω |
| Coil Inductance (Le) | 0.19m H |
| Mechanical Q (Qms) | 5.68 |
| Electromagnetic Q (Qes) | 0.6 |
| Total Q (Qts) | 0.54 |
| Compliance Equivalent Volume (Vas) | 5.8 liters / 0.2 cu.ft. |
| Peak Diaphragm Displacement Volume (Vd) | 44 cc |
| Mechanical Compliance of Suspension (Cms) | 0.26 mm/N |
| BL Product (BL) | 8 T-M |
| Diaphragm Mass Inc. Airload (MMs) | 7 grams |
| Efficiency Bandwidth Product (EBP) | 159 |
| Maximum Linear Excursion (Xmax) | 3.5 mm |
| Surface Area of Cone (Sd) | 126.7 cm2 |
| Maximum Mechanical Limit (Xlim) | 4.0 mm |
| MOUNTING INFORMATION | |
| Recommended Enclosure Volume | |
| Sealed | 2.80-5.70 liters / 0.10-0.20 cu.ft. |
| Vented | 3.40-15.60 liters / 0.12-0.55 cu.ft. |
| Driver Volume Displaced | 0.014 cu.ft. / 0.41 liters |
| Overall Diameter | 6.59", 167.4 mm |
| Baffle Hole Diameter | 5.65", 143.5 mm |
| Front Sealing Gasket | Yes |
| Rear Sealing Gasket | Yes |
| Mounting Holes Diameter | 0.23", 5.8mm |
| Mounting Holes B.C.D. | 6.06", 153.9mm |
| Depth | 2.8", 71.1 mm |
| Net Weight | 4.1 lbs, 1.86 kg |
| Shipping Weight | 4.8 lbs, 2.18 kgs |
| MATERIALS OF CONSTRUCTION | |
| Coil Construction | Copper voice coil |
| Coil Former | Polyimide former |
| Magnet Composition | Ferrite magnet |
| Core Details | Vented and extended core |
| Basket Materials | Pressed steel basket |
| Cone Composition | Paper cone |
| Cone Edge Composition | Cloth cone edge |
| Dust Cap Composition | Solid composition paper dust cap |
